U Beam

Aluminum bars responsible for completing the honeycomb sheets of the polycarbonate roof. This configuration provides protection for the closing lines as well as guaranteeing excellent aesthetic qualities of the construction.

Constructions that require a material that is both light and resistant.

Order Now
h (in.) h (cm) Area (cm²) bf tf tw Weight (kg/m)
3" 7,62 7,78 3,58 0,69 0,43 6,11
3" 7,62 9,48 3,80 0,69 0,66 7,44
4" 10,16 10,10 4,01 0,75 0,46 7,95
4" 10,16 11,90 4,18 0,75 0,63 9,30
6" 15,24 15,50 4,88 0,87 0,51 12,20
6" 15,24 19,90 5,17 0,87 0,80 15,60
8" 20,32 21,68 57,40 0,95 0,56 17,10
8" 20,32 25,9 59,4 0,9 0,7 20,50
10" 25,40 29,00 66,04 1,11 0,61 22,77
10" 25,40 37,90 69,57 1,11 0,96 29,76
h (pol.) h (cm) Axis X Axis Y
j
(cm4) 		W
(cm3) 		r
(cm) 		j
(cm4) 		W
(cm3) 		r
(cm) 		X
(cm)
3" 7,62 68,90 18,10 2,98 8,20 3,32 1,03 1,11
7,62 77,20 20,30 2,85 10,30 3,82 1,04l 1,11
4" 10,16 159,50 31,40 3,97 13,10 4,61 1,14 1,16
10,16 174,40 34,30 3,84 15,50 5,10 1,14 1,15
10,16 190,60 37,50 3,73 18,00 5,61 1,15 1,17
6" 15,24 546,00 71,70 5,94 28,80 8,16 1,36 1,30
15,24 632,00 82,90 5,63 36,00 9,24 1,34 1,27
15,24 724,00 85,00 5,42 43,90 10,50 1,33 1,31
8" 20,32 1344,30 132,70 7,87 12,94 1,42 1,47
20,32 1490,00 147,50 7,59 14,09 1,42 1,42
10" 25,40 2800,00 221,00 9,84 95,00 19,00 1,81 1,61
25,40 3290,00 259,00 9,31 117,00 21,60 1,76 1,54
